Advertising Display Seamless Video Wall Lcd Monitors , Indoor Lcd Wall Display

    Buy cheap Advertising Display Seamless Video Wall Lcd Monitors , Indoor Lcd Wall Display from wholesalers

    Buy cheap Advertising Display Seamless Video Wall Lcd Monitors , Indoor Lcd Wall Display from wholesalers
    • Buy cheap Advertising Display Seamless Video Wall Lcd Monitors , Indoor Lcd Wall Display from wholesalers
    • Buy cheap Advertising Display Seamless Video Wall Lcd Monitors , Indoor Lcd Wall Display from wholesalers

    Advertising Display Seamless Video Wall Lcd Monitors , Indoor Lcd Wall Display

    Ask Lasest Price
    Brand Name : ZXTLCD
    Model Number : LTI460HN09
    Certification : CE/Rohs/FCC/ERP Energy Label
    Price : Negotiate
    Payment Terms : T/T,Western Union, Alibaba trade assurance
    Supply Ability : 3.000 pcs per month
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    Advertising Display Seamless Video Wall Lcd Monitors , Indoor Lcd Wall Display

    China Advertising Display Producer Full Sexy Video 1080p Full HD China Seamless Matrix LCD Video Wall


    Features

    1. Ultra-narrow edge mosaic wall, the narrowest bilateral border can reach 1.8mm, the real seamless mosaic video wall.

    2. Bright LCD, LCD screen brightness up to 700cd / m2, but also according to the brightness of the surrounding environment, automatically adjust the screen brightness.

    3. Ultra-high resolution, single-screen display resolution of 1920 × 1080, full screen mosaic display resolution is a single screen multiples.

    4. Video mosaic wall matrix display capabilities, built-in image magnification processor, supports a variety of video wall format, enabling 2 × 2, 3 × 3 ... m × n any installation splicing, free to support M × N, such as 256 screen Phase stitching. The signal receiver does not require an additional signal distributor.

    5. High reliability, stability, stitching splicing wall support 7 × 24 hours of continuous operation. Highly reliable industrial power supply design, heat flow guide design to ensure stable operation.

    6. Software control, stitching software centralized control system, the monitor splicing methods, size, contrast, brightness, color and other control, easy to operate, fast.

    Specifications:

    arametersnew advertising lcd screen
    Panelsize46inch*9 pcs
    Type3*3
    Module size1018.353*572.544MM
    BrandSAMSUNG
    resolution1920*1080
    brightness450cd/m*2
    Pixel pitch0.7455(h)x0.7455(v)mm
    Surface TreatmentHaze5.5%, Hard-coating(3h)
    Display Colors8bit-16.7m
    Pixel ArrangementRGB Vertical Stripe
    Display ModeNormally Black
    view angle178°/178°(H/V)
    Gap6.7MM or 5.3MM
    Flooring standOptional
    Large-screen managementSystem management and control software, software copyright patent; control software, a variety of signal switching, spliced into a single-screen display, a combination of screen body, full screen display
    Signal distributor (processor)HDMI,1 input,16 output
    Wire3M Control line
    TFT panel gradeImported new panel
    BracketCold rolled steel with powder coating
    PackageExport wooden box+carton
    box with 5 ply+4cm foamy
    Standard operation softwarefree

    DID LCD splicing screen can be any combination: either large screen splicing, small screen splicing; either single-screen display, you can also splicing the entire screen. According to customer requirements for the application of LCD splicing screen system and system size, according to the actual application environment, select the appropriate splicing methods and the best products, design personalized programs to meet customer needs.

    Video Wall Controller(Built-in each Screen)
    InputCVBS3*BNC inputs, support PAL/NTSC all formats, 2*BNC loop outputs
    VGA1*D15 port, support SVGA/XGA/WXGA
    YPbPr/YCbCr1* YPbPr/YCbCr input, support PAL/NTSC all formats, and 720P,1080I, HDTV
    Y/C2*BNC inputs, support PAL/NTSC all formats
    OutputLVDSSupport signal or double LVDS output, and WUXGA (1920*1080) display
    Operate modePanel key operation(Customized)
    Standard RS232 port( provide free control software)
    Infrared Remote Control Operation
    Engineering softwareCustomized
    Working temperature0~70 °C
    working humidity5~95 %RH
    AC voltage power supply100-240V/50, 60Hz
    power consumptionMax 300W,according to different Screen models
    Dimension338×295×60(mm)
    WeightAbout 3.5KG

    Advantages
    Wall mounted or floor standing.
    Play the same content or different content at the same time,share the picture on all screen or not.
    46" Samsung ultra narrow screen with only 6.7mm and 55” only with 5.3mm gap.
    LG video wall for your choice.
    DIY any size into a big screen.
    System management and control software, software copyright patent; control software, a variety of signal switching, spliced into a single-screen display, a combination of screen body, full screen display
    Controlling device:PC,tablet,notebook,DVD player,video etc.
    Easy controlled to play and manage.
    Auto cycle display 7/24/365.
    One year warranty for whole machine from our professional after sale department.

    Advertising Display Seamless Video Wall Lcd Monitors , Indoor Lcd Wall Display

    Advertising Display Seamless Video Wall Lcd Monitors , Indoor Lcd Wall Display


    Application areas

    1. Airports, ports, terminals, subways, highways and other transport industry information display terminal

    2. Financial, securities information display terminal

    3. Commercial, media advertising, product display and other display terminals

    4. Education and training / multimedia video conferencing system

    5. Scheduling, control room six, radio and television, large-scale studio/performance venues

    6. Military, government, city and other emergency command system

    7. Mining, energy security monitoring system

    8. Fire, meteorology, maritime, flood control, transport hub command system


    Pakage details: Inner 4CM PE foam, middle export carton box,outer export wooden box


    Shipping Method
    By Express(DHL/UPS/FEDEX)3~5days, door to door
    By Air5~7days, to the Airport Only
    By Sea5~30days, to the Seaport Only, depend to the Country
    EXW FactoryAll cost bared by client
    FOB ShenzhenArrange the goods to the ship, after that all cost bared by client
    Delievery Time
    Regular Sample7~15days once receive deposit
    Customize Sample30~35days once receive deposit
    Quantity Order15~20days once receive deposit
    Payment Term
    Western Union50% in advance with order, 50% before shipment
    T/T50% in advance with order, 50% before shipment
    Warranty Time: ONE year since Client Receive the Good
    Under WarrantySeller will Bare the problems if cause by unartificial
    Out of WarrantyBuyer will Bare the problems, Seller will support help if needed

    Payment Items

    1. Payment Ways

    a. Pay by T/T: 50% deposit, the ballance before shipping.

    b. Pay by Western Union

    2. Delivery Ways:

    a. By Express ( DHL / UPS / TNT / Fedex for option), it takes about 4-9 working days

    b. By Air: It will takes 5-10 days

    c. By shipping. It will takes 15-35 days (according the place of your local port)

    3. Leading Time:

    a. Sample: 10-15 working days ( For standard products)

    b. Bulk order: 15-35 working days ( Less than 1000 pcs)

    c. Customized Products

    1) Design Structure: 20-35 working days

    2) Sample: 15-20 working days
